RC(S)(L)(D)10-Series Installing the refrigerator
15
Refrigerator depth (C)
(excludes control knob 5 mm)
450 mm 485 mm
Recess height (H) 828 mm 982 mm
Recess width (W) 425 mm 425 mm
Recess depth (D) 452 mm 487 mm
RC10.4P.100 RC10.4M.90
Refrigerator height (A) 900 mm 901 mm
Refrigerator width (B) 420 mm 420 mm
Refrigerator depth (C)
(excludes control knob 5 mm)
655 mm 485 mm
Recess height (H) 907 mm 908 mm
Recess width (W) 425 mm 425 mm
Recess depth (D) 657 mm 487 mm
RCD10.5(S)(T) RCD10.5X(S)(T)
Refrigerator height (A) 1282 mm 1282 mm
Refrigerator width (B) 523 mm 523 mm
Refrigerator depth (C)
(excludes control knob 5 mm)
565 mm 620 mm
Recess height (H) 1290 mm 1290 mm
Recess width (W) 528 mm 528 mm
Recess depth (D) 568 mm 623 mm
RCL10.4(S)(T) RCL10.4E(S)(T)
Refrigerator height (A) 1293 mm 1293 mm
Refrigerator width (B) 420 mm 420 mm
Refrigerator depth (C)
(excludes control knob 5 mm)
595 mm 595 mm
Recess height (H) 1301 mm 1301 mm
RC10.4(S)(T).70 RC10.4(S)(T).90
