RC(S)(L)(D)10-Series Technical data
19
RC10.4M.90 (fig. 9, page 8)
➤ Connect the control panel (2) to the refrigerator (3) via the lightning cable (4).
➤ Connect the control panel (2) to the compressor unit (1) via the data cable (5).
➤ Install the control panel as shown (fig. 9, page 8).
5 Technical data
For the current EU declaration of conformity for your device please refer to the
respective product page on dometic.com or contact the manufacturer directly
(see dometic.com/dealer).
This device complies with UN ECE Regulation R10.05.2014.
Depending on the model, the refrigerator uses either R134a or R600a as refrigerant.
Refer to the data plate for the refrigerant used.
For R134a models applies:
This product contains fluorinated greenhouse gases.
The cooling unit is hermetically sealed.
No. in
fig. 9,
page 8
Description
1 Compressor unit
2 Control panel
3 Refrigerator
4 Lightning cable (3.5 m)
5 Data cable (3.5 m)
