Dometic RF60 - Product View; Energy Selector Switch

2
Note:
The refrigerator is equipped to operate mains power, DC or liquid gas.
The desired power option is selected by means of energy selector switch (A).
Energy selector switch (A) has four settings: AC mains power, DC (12V),
Gas (liquid gas), O (Off).
Figure 1
Figure 2
A. Energy selector switch D. Manual ignition button
B. Flame indicator (galvanometer) E. Door lock
C. Thermostat (Gas/electric)
A
Off
AC
DC
Gas
E B C D
A
