RML9330 – RML9435 Installing the refrigerator
21
6.5 Install the roof vent
➤ Ensure the installation frame is water resistant (fig. e, page 7).
➤ Insert the installation frame and screw it down tightly (fig. e, page 7).
➤ Insert the hood and screw it down tightly (fig. f, page 7).
6.6 Install the flue duct
I
The flue duct is installed at the factory. Follow these steps when you have
removed the flue duct and want to reinstall it (fig. g, page 7):
➤ Place the T-piece (1) on the adaptor (2) and the flue pipe (3).
➤ Direct the T-piece at an angle of 45° towards the rear wall.
➤ Attach the T-piece, adaptor and flue pipe with a screw (4).
No. in
fig. d, page 6
Description
1 Installation frame
2Hood
NOTE
Do not install an additional flue stack, as this leads to poor
performance and increases the power consumption of the
refrigerator.
