RML9330 – RML9435 Connecting the refrigerator
27
➤ Connect the RML9331/9335/9431/9435 refrigerators as follows (fig. v,
page 11):
Item Description
1 Heating cartridge AC power
2 AC power connection cable
3 Earth AC power
4 Ionisation
5 Ignition
6 Burner
7 Heating cartridge DC power supply
8 Heating cartridge DC power
9 LED lighting
10 Electronics DC power supply
11 Gas inlet
12 Gas outlet
13 Gas valve
14 DC power outlet
15 Gas valve supply line
A Optional connections to DC power outlet
B Negative terminal (–) DC permanent supply for electronics
C Positive terminal (+) DC permanent supply for electronics
D Connection D+
E Connection S+
F Heating element positive terminal (+) DC power
G Heating element earth terminal DC power
