Chapter 1 Use and Maintenance
Unit 1 Main technical Parameter
1.1 Basic Parameter
1.1.1 Basic dimension & Weight Parameter (Form 1-1)
Form 1-1 Basic dimension & Weight Parameter
Items Parameters
1. Dimension (mm)
C35
Total Length
4500
Total Width 1680
C35
Total Height (empty)
2000
C35
Wheelbase (mm)
2515
Fr.Tread (mm) 1435
Rr.Tread (mm) 1435
2. Weight
Mass of the vehicle with bodywork in
running order
C35
948 ~ 980
2、Performance Parameter (Form 1-2)
Form 1-2 Performance Parameters
Items Parameters
Optional Model of Engine DK15-06 SFD12C
（km/h）Max speed 135 105
Max Climbing Capacity 32 30
Time-Needed from Start and then with
continuous gear-swift to accelerate 90km/h
40 48
Economical Fuel Consumption Under Limited
Condition like 50Km/h, etc
≤6.5 ≤6
（50km/h）Brake Distance ≤20
Outside Noise While Speeding up (dB) ≤74
1.2 Structure parameter
1、Main Technical Parameter of Engines (Form 1-3 )
Form 1-3 Main Technical Parameters of Engines
DK15-06 SFD12C
Model
Items
