Circuit Diagrams of Electrical Appliances
21-95
IC07F: cockpit harness—rear harness (20P White) (S30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 810C Red SP16 11
2 12 6206 Green D001E
3 2651B Yellow D001E 13
4 14 2620 Brown D001E
5 310 Red D001E 15
6 2320 Red IC04M 16 6265 Green D001I
7 17 6260 Yellow D001I
8 2325 Red IC04M 18 2625 Green D001E
9 2201 Brown IC04M 19
10 20 2100B Green IC04M
IC08F: cockpit harness—left rear door harness (10P Black) (S30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 6200C Red SP12 6
2 6022 Brown IC06F 7 6023 Red D001E
3 6210C Green S006 8 MC623 Green yellow SG14
4 8421 Brown IC04M 9 6024 Green IC06F
5 8420 Yellow IC04M 10 6201C Brown SP11
IC09F: cockpit harness—right rear door harness (10P Black) (S30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 6200D Red SP12 6
2 6027 Grey IC06F 7 6028 Yellow D001E
3 6210D Brown S006 8 MC624 Green yellow SG14
4 8426 Red IC04M 9 6029 Yellow IC06F
5 8425 Green IC04M 10 6201D Red SP11
