Circuit Diagrams of Electrical Appliances
21-100
Cabin harness (H30)
manual transmission+manual air conditioning VIN<037957
manual transmission+automatic air conditioning VIN<038052
automatic transmission+manual air conditioning VIN<037831
automatic transmission+automatic air conditioning VIN<037836
IC04M: cockpit harness--instrument panel harness (22P White) (H30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 7020 White D7020 12 6017 Yellow IC06F
2 7021 Red D7020 13 2325 Yellow IC07F
3 2320 Milk white D2620 14 601 Pink IC06F
4 2330 Yellow IC06F 15 6411 White IC06F
5 8425 Green IC09F 16 8426 Red IC09F
6 6412 Blue IC06F 17 6401 Yellow IC06F
7 8420 Yellow IC08F 18 8421 Brown IC08F
8 1202 Red D1211 19 7026 Brown D7025
9 7025 Green D7025 20 8411 Pink IC06F
10 8410 Grey IC06F 21 2100B Green IC07M
11 2201 Brown S017 22 6019 Red IC06F
IC06F: cockpit harness--left front door harness (20P Yellow) (S30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 MC71 Green yellow G71 11 6401 Yellow IC04M
2 6029 Yellow IC09F 12 6205 Green D001I
3 6027 Grey IC09F 13 810B Brown SP16
4 6024 Green IC08F 14 2330 Yellow IC04M
5 6022 Brown IC08F 15 6201A Green SP11
6 6019 Red IC04M 16 6412 Blue IC04M
7 6017 Yellow IC04M 17 6200A Red SP12
8 601 Pink IC04M 18 6411 White IC04M
9 6250 Brown D001I 19 8410 Grey IC04M
10 6210A Red S006 20 8411 Pink IC04M
