Sunroof
15-11
3. Assembly
Attention: tightening torque of glass mounting screw (1): 5±0.5N·m.
Assembly is in the reverse order of the disassembly.
4. Inspection
Connect battery negative cable;
Turn ignition key to “ACC” position;
Operate sunroof control button to check whether the sunroof glass installed is in normal working
condition.
Refer to the following operation:
Opening backward
Press Slide button (less than 0.5 sec) make
glass panel drive sun visor to slide to maximum
position;
During the opening and sliding of glass panel,
press Slide button (less than 0.5 sec) again to
stop glass in the present position;
Press and hold Slide button (more than 0.5
sec). During the opening and sliding of glass
panel, release the button to stop glass panel.
Closing forward
When sunroof is in open state, press Tilt button
(less than 0.5 sec) to make all the glass panels
close automatically;
During the closing and sliding of glass panel,
press Tilt button (less than 0.5 sec) again to
stop glass in the present position;
Press and hold Tilt button (more than 0.5 sec).
During the closing and sliding of glass panel,
release the button to stop glass panel;
Pull back sun visor with hand to close it.
Tilted opening
When sunroof is in close state, press Tilt
button to make the rear of glass panel tilt and
open. Pull back sun visor with hand to open it.
Tilted closing
When sunroof is in tilt and open state, press
Slide button to descend and close glass panel;
Pull back sun visor with hand to close it.
Tips: upon the completion of above operation, perform water pouring test to sunroof to
ensure the sound tightness of sunroof.
