Circuit Diagrams of Electrical Appliances
21-34
List of hinge points of engine harness (MT) (S30/H30)
Hinge
point
Conductor
No.
Colour No.1 terminal
Electrical
appliance
No.
No.2 terminal
Electrical
appliance
No.
S002 6739B Blue IC20F S002
一
6739A Blue Engine computer D1320A S002
- 6739 Brown S002 Speed sensor D1620
S008 1599 Red Engine computer D1320A S008
一
1599A Green S008 IC20F
- 1599B Green S008 IC20F
S021 1150B
一
CAP S021
一
1150A White Ignition coil D1135 S021
- 1150 Green S021 SP04
SD01 MC135
Green
yellow
SG05 SD01
一
Drain
一
SD01 Drain
-
SG03 MC32
Green
yellow
G32 SG03
一
MC131
Yellow
green
SG03 Engine computer D1320A
- MC132
Yellow
green
SG03 Engine computer D1320A
SG05 MC802
Green
yellow
Air condition compressor D8010 SG05
一
MC671
Green
yellow
Speed sensor D1620 SG05
- MC135
Green
yellow
SG05 SD01
一
MC33
Yellow
green
SG05 G33
SP04 1351 White IC19F SP04
一
1204B Yellow IC20F SP04
- 1150 Green SP04 S021
一
1320 Green SP04 IC10F
- 1351A Grey SP04 Front oxygen sensor D1350
一
1351B Grey SP04 Rear oxygen sensor D1351
- 1355 Brown SP04 Canister purge valve D1215
一
672 Yellow SP04 Speed sensor D1620
SP03A 1229 Blue IC19F SP03A
一
1229B Red IC19F SP03A
- 1229A Blue SP03A Engine computer D1320B
