Circuit Diagrams of Electrical Appliances
21-37
List of hinge points of cockpit harness(S30/H30)
Hinge
point
Conductor
No.
Colour No.1 terminal
Electrical
appliance
No.
No.2 terminal
Electrical
appliance
No.
S006 6210D Brown IC09F S006
一
6210C Green IC08F S006
一
6210 Red S006 Cabin fuse box D001I
一
6210A Red S006 IC06F
SG14 MC623
Green
yellow
IC08F SG14
一
MC71A
Green
yellow
G71 SG14
- MC121
Green
yellow
SG14 Fuel pump D1210
一
MC122
Green
yellow
SG14 Oil level sensor D1211
一
MC624
Green
yellow
SG14 IC09F
SP11 6201D Red IC09F SP11
一
6201C Brown IC08F SP11
一
6201 Grey SP11 Cabin fuse box D001E
一
6201A Green SP11 IC06F
SP12 6200D Red IC09F SP12
一
6200C Red IC08F SP12
- 6200 Green SP12 Cabin fuse box D001E
一
6200A Red SP12 IC06F
List of hinge points of cockpit harness (S30)
SP16 810C Red IC07F SP16
- 810A Yellow SP16 Cabin fuse box D001E
一
810B Brown SP16 IC06F
SP307 6250B Brown IC06F SP307
- 6250A Brown SP307 IC04M
一
6250 Brown SP307 Cabin fuse box 0001I
