Circuit Diagrams of Electrical Appliances
21-41
List of hinge points of main backdoor harness (H30)
Hinge
point
Conductor
No.
Colour No.1 terminal
Electrical
appliance
No.
No.2 terminal
Electrical
appliance
No.
S001 MC500 Grey No.3 brake lamp D2100 S001
一
MC501A
Yellow
green
SDL S001
- MC501
Yellow
green
S001 IC07F
List of hinge points of backdoor harness branch (H30)
Hinge
point
Conductor
No.
Colour No.1 terminal
Electrical
appliance
No.
No.2 terminal
Electrical
appliance
No.
S002 MC263B
Green
yellow
Left license plate lamp D2630 S002
一
MC266
Green
yellow
Right license plate lamp D2635 S002
- MC626
Yellow
green
Hatchback door switch D6265 S002
一
MC820
Yellow
green
Rear window defroster- D820B S002
- MC501
Yellow
green
S002 SDR
一
MC521
Green
yellow
S002 Rear wiper motor D501A
- MC625
Green
yellow
S002 Hatchback door lock D6260
