DongFeng S30 - Page 52

Circuit Diagrams of Electrical Appliances
21-43
List of hinge points of left front door harness (S30/H30)
Hinge
point
Conductor
No.
Colour No.1 terminal
Electrical
appliance
No.
No.2 terminal
Electrical
appliance
No.
S012 6402 Green IC17F S012
- 6400 Green S012 Rearview mirror regulator D641
- 6401 Green S012 IC06M
S016 8411A Brown Bass horn D8410A S016
- 8411 Brown S016 IC06M
- 8411B Brown S016 Tweeter D8410B
List of hinge points of left front door harness (S30/H30)
(Applicable to the last six digits of VIN<005834)
Hinge
point
Conductor
No.
Colour No.1 terminal
Electrical
appliance
No.
No.2 terminal
Electrical
appliance
No.
S015 8410A Green Bass horn D8410A S015
- 8410 Red S015 IC06M
- 8410B Green S015 Tweeter D8410B
SG16 MC621A
Green
yellow
IC06M SG16
- MC621
Yellow
green
Door lock D6210 SG16
- MC601
Green
yellow
SG16
Main window regulator
switch
D6000
- MC620
Green
yellow
SG16
Main window regulator
switch
D6000
- MC641
Yellow
green
SG16 IC17F
- MC641A
Yellow
green
SG16 Rearview mirror regulator D641
SP19 601 Pink IC06M SP19
- 601A Brown SP19
Main window regulator
switch
D6000
- 641 Red SP19 Rearview mirror regulator D641
