DongFeng S30 - Page 60

Circuit Diagrams of Electrical Appliances
21-51
IC14M: instrument panel harness--SRS harness (10P Green) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 652 Brown D001B ALL 6
2 6501 Green D004B ALL 7
3 8 6502 Brown D001H ALL
4 9006A Brown D003 ALL 9
5 6503 Green D004A ALL 10
IC15AF: instrument panel harness--driver airbag (2P Yellow) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 6510 Orange IC15M ALL 2 6511 Yellow IC15M ALL
IC15M: instrument panel harness--SRS harness (2PBrown) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 6510 Orange IC15AF ALL 2 6511 Yellow IC15AF ALL
IC16M: instrument panel harness--SRS harness (2P Green) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 6515 Orange ICI6AF ALL 2 6516 Yellow ICI6AF ALL
IC16AF: instrument panel harness--passenger airbag (2P Green) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 6515 Orange IC16M ALL 2 6516 Yellow IC16M ALL
IC22F: instrument panel harness--front harness (20P White) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 010E Yellow SP10 C/F 11 1623 Red D1603 C/F
2 1622 Blue D1603 C/F 12 1620 Brown D1603 C/F
3 13
4 1621 Grey D1603 C/F 14
5 1631 Green D1604 C/F 15
6 1632 Grey D1604 C/F 16
7 7309 Red D210A C/F 17
8 18
9 1625 Yellow D1603 C/F 19 9000 Green D004A C/F
10 1624 Green D1603 C/F 19 9000B Green D003 C/F
20 9001 Brown D004A C/F
20 9001B Brown D003 C/F
