Circuit Diagrams of Electrical Appliances
21-70
Front harness (S30)
A
manual transmission+manual air
conditioning
B
manual transmission+automatic air
conditioning
C
automatic transmission+manual air
conditioning
D
automatic transmission+automatic air
conditioning
VIN<015982
ALL Shared
IC01M: front harness--instrument panel harness (22P Brown) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 2605 Pink SP05B ALL 12 8077 Green D801 ALL
2 012B Yellow IC19M A/B 13 5011 Yellow D001F ALL
2 012D Grey D1602B C/D 14 7031 Red D703 ALL
3 2201 Green IC20M A/B 15 1560 Yellow IC20M ALL
3 2201A Green D16028 C/D 16 003B Blue SP26 ALL
3 2201B Yellow D16018 C/D 17 2641 Green D002 ALL
4 2310 Brown D2610A ALL 18 1368 Red IC20M ALL
5 1330 Red IC19M ALL 19 8081 Blue IC20M ALL
6 1392 Brown IC20M ALL 20 4121 Yellow IC19M ALL
7 4001 Yellow IC19M ALL 21 8001 Grey IC20M A/D
8 2315 Brown D2615A ALL 21 8001A Red D002 B/C
9 8080 Green IC19M ALL 22 1011 Green IC19M A/B
10 5014 Grey D501 ALL 22 1610 Green D1602B C/D
11 002- Yellow SP23 ALL
IC02M: front harness--instrument panel harness (26P White) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 2606 Pink SP05A ALL 15 6739 Green S002A A/B
2 012C Yellow D700 ALL 15 6739F Green S002C C/D
3 8200 Red IC19M ALL 16
4 7002 Brown D700 ALL 17
5 8269 Blue IC19M ALL 18
6 602A Brown D002 ALL 19 1599B Red IC20M ALL
7 1012 Red IC19M ALL 20 602 Red SPWD0 ALL
8 2500 Blue D002 ALL 21
9 9006B Yellow IC20M ALL 22 5112 Yellow D510 ALL
10 601B Pink SPWD0 ALL 23 7020 Green D700 ALL
11 7003 Blue D700 ALL 24 7021 Brown D700 ALL
12 5016 Brown D501 ALL 25 7025 Green D700 ALL
13 2100 Green D700 ALL 26 7026 Brown D700 ALL
14 5111 Green D510 ALL
To Next Page
