Circuit Diagrams of Electrical Appliances
21-75
IC21M: front harness--cooling fan harness (6P White) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 1592 Green IC19M ALL 4 1590 Grey D002 ALL
2 1595 Brown IC20M ALL 5 1599A Yellow IC20M ALL
3 002C Blue SP23 ALL 6 150 Black D002 ALL
IC22M: front harness--instrument panel harness (20P White) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 160 Yellow D1601A C/D 11 1623 Red D1601B C/D
2 1622 D1601B C/D 12 1620 Brown D1601B C/D
3 13
4 1621 Grey D1601B C/D 14
5 1631 Green D002 C/D 15
6 1632 Grey D002 C/D 16
7 7309 Red IC19M C/D 17
8 18
9 1625 Yellow D1601B C/D 19 9000 Green D1601A C/D
10 1624 Green D1601B C/D 19 9000A Green IC20M C/D
20 9001 Brown D1601A C/D
20 9001A Brown IC20M C/D
