Circuit Diagrams of Electrical Appliances
21-77
IC03M: front harness--instrument panel harness (2P Brown) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 260 White D002 ALL 2 803 Red D002 ALL
IC19M: front harness--engine harness (26P White) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 1229B Red D1256 ALL 15 1228 Green D002 ALL
2 8076 Green D801 ALL 16 6739E Green S002C C/D
3 1012 Red IC02M ALL 17 4121 Yellow IC01M ALL
4 1229 Blue D002 ALL 18 8269 Blue IC02M ALL
5 1592 Green IC21M ALL 19 1330 Red IC01M ALL
6 1203 Grey D002 ALL 20
7 8200 Red IC02M ALL 21 012B Yellow IC01M A/B
8 8080 Green IC01M ALL 22 1011 Green IC01M A/B
9 4001 Yellow IC01M ALL 22 1611A Green D002 C/D
10 1204A Green SP03 ALL 23
11 24 7309 Red IC22M C/D
12 25
13 26
14
IC20M: front harness--engine harness (22P White) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 1204B Grey SP03 ALL 12 8001 Grey IC01M A/D
2 1377 Red D1261 ALL 12 8001B Grey D002 B/C
3 6739B Blue S002A A/B 13 1560 Yellow IC01M ALL
4 9000A Green IC22M C/D 14 1392 Brown IC01M ALL
5 9001A Brown IC22M C/D 15 1368 Red IC01M ALL
6 1378 Green D1261 ALL 16
7 8081 Blue IC01M ALL 17 1380 Yellow D1261 ALL
8 132A Green SP24 C/D 18 1599A Yellow IC21M ALL
8 132B Green D002 A/B 19 9006B Yellow IC02M ALL
9 1599B Red IC02M ALL 20 1379 Brown D1261 ALL
10 1595 Brown IC21M ALL 21
11 2201 Green IC01M A/B 22
To Next Page
