Circuit Diagrams of Electrical Appliances
21-85
SRS harness
A SRS (without sidebag)
B&C SRS (with sidebag)
ALL Shared
IC14F: SRS harness--instrument panel harness (10P Green) (S30/H30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 652 Brown D650 ALL 6
2 6501 Green D650 ALL 7
3 8 6502 Brown D650 ALL
4 9006A Brown D650 ALL 9
5 6503 Green D6502 ALL 10
IC15F: SRS harness--instrument panel harness (2P Brown) (S30/H30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 6510 Orange D650 ALL 2 6511 Yellow D650 ALL
IC16F: SRS harness--instrument panel harness (2P Green) (S30/H30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 6515 Orange D650 ALL 2 6516 Yellow D650 ALL
