Circuit Diagrams of Electrical Appliances
21-88
Engine harness (MT) 015982≤VIN<037957
IC10F: engine harness (MT)--ejector harness (6P Grey) (S30/H30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 1321 Grey D1320C 4
2 1322 Grey D1320C 5 1323 Green D1320C
3 1320 Green SP04 6 1324 Green D1320C
IC19F: engine harness (MT)-- front harness (26P White) (S30/H30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 14
2 8076 Blue D1320A 15 1228 Red D1203
3 1012 Green D102 16
4 1229 Blue D1320B 17 4121 Red D412
5 1592 Yellow D1320A 18 8269 Green D1320A
6 1203 Green 013203 19 1330 Red D1320A
7 8200 Brown D1320A 20
8 8080 Yellow D1320A 21 012B Green D220
9 4001 Green D4005 22 1011 Yellow D101
10 1351 White SP04 23
11 24
12 25
13 26
IC20F: engine harness (MT)-- front harness (22P White) (S30/H30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 12048 Yellow SP04 12 8001 Green D8010
2 1377 Red D1320A 13 1560 Brown D1320A
3 67398 Blue S002 14 1392 Red D1320A
4 15 1368 Brown D1320A
5 16
6 1378 Green D1320A 17 1380 Yellow D1320A
7 8081 Green D1320A 18 1599A Green S008
8 132A Green D1320A 19 9006 Yellow D1320A
9 1599B Green S008 20 1379 Brown D1320A
10 1595 Blue D1320A 21
11 2201 Grey D220 22
