Set MIDI channel (software channel).
D0 = Reserved, set it to ‘0’
D1 = TX channel value 0-15 for channel 1-16
D2 = RX channel value 0-15 for channel 1-16. 16 means all channels
0E D0 D1 D2
Set MIDI in transpose.
D0 = transpose value 0 - 24 for transpose -12 to + 12 (value 12 is no
transpose)
0F D0
Set key priority.
D0 = Key priority, 0—Low, 1—Hight, 2--Last
12 D0
Set multi trigger.
D0 = Multi trigger, 0-off (slide), 1-on, 2-off (legato)
D1 = Reserved, set it to ‘0’
14 D0 D1
Set sync clock polarity.
D0 = Sync polarity, 0 – fall, 1 – rise
D1 = Reserved, set it to ‘0’
19
Set sync clock rate
D0 = clock rate, 0 – 1 PPS, 1 – 2 PPQ, 2 – 24 PPQ, 3- 48 PPQ,
1A
D0 D1
D0
Set sync clock source.
D0 = clock source, 0 – Internal, 1 – MIDI, 2 – USB, 3 – TRIG,
4 – Automatic
1B D0
Set accent velocity threshold.
D0 = Accent velocity threshold, value 0–127
1C D0
Set midi soft through configuration.
D0 = DIN to USB, 0 – Disable, 1 – Enable
D1 = DIN to DIN, 0 – Disable, 1 – Enable
D2 = USB to DIN, 0 – Disable, 1 – Enable
28 D0 D1 D2
Set midi forwarding.
D0 = Keyboard midi forwarding:0 - OFF, 1 –DIN, 2 – USB, 3 -BOTH
D1 = Sequencer midi forwarding:0 - OFF, 1 –DIN, 2 – USB, 3 -BOTH
D2 = Arpeggiator midi forwarding:0 - OFF, 1 –DIN, 2 – USB, 3 -BOTH
D3 = Realtime midi forwarding:0 - OFF, 1 –DIN, 2 – USB, 3 -BOTH
D4 = Reserved, set it to ‘0’
D5 = Reserved, set it to ‘0’
D6 = Reserved, set it to ‘0’
17
D0 D1 D2
D3 D4 D5
D6
Packet
number
Parameter
payload
Function
System Exclusive Table:
01 02 03 04 05 06 07
08 09 10 11 12 13 14 15
16 17 18
19 20 21 22 23 24 25
26 27 28 29 30 31 32 33
34 35 36
37 38 39 40 41 42 43
44 45 46 47 48 49 50 51
52 53 54
55 56 57 58 59 60 61
62 63 64 65 66 67 68 69
70 71 72
73 74 75 76 77 78 79
80 81 82 83 84 85 86 87
88 89 90
91 92 93 94 95 96 97
98 99 100 101 102 103 104 105
106 107 108 109
