Dorel DA7867 - Main Body Construction

STEP 2
Kitchen Island with 2 Stools
DA7867
Insert cam bolts (1) into right side panel (B).
Insert cam locks (2) into the upper rail (C) and bottom rail (E) as shown
Attach upper rail (C) and bottom rail (E) to right side panel (B) and secure by rotating cam locks (2)
1/2-turn clockwise using Phillips head screwdriver (not included).
Slide back panel (D) into the grooves of the rails (C & E) and right side panel (B).
