19
Item Art. No. Description No.
1 300741 Motor complete 1
2 200839 Motor casing 1
3 401554 Magnet casing 1
4 900011 Hexagon socket set screw 1
5 900229 Washer 1
6 800076 Locking washer 5
7 900412 Flat-head screw 1
8 300068 Brush bridge 1
9 800064 Carbon brush 2 **
10 900180 Spring washer 2
11 900332 Cheese-head screw 2
12 900183 Wave spring washer 4
13 900399 Slotted cheese head screws 2
14 400036 Air baffle disc 1
15 302099 Switch box 1
16 802733 Cable grommet 1 **
17 801263 Toggle switch 1
18 900458 Countersunk screw 2
19 800174 Protective cap 1 **
20 401334 Cover plate 1
21 401667 Attempt current limiters 1
22 801354 Interference-suppression capacitor 1
23 900704 Hexagon socket head cap screw 4
24 400943 Armature 1
25 900483 Grooved ball bearings 1 **
26 900329 Grooved ball bearings 1 **
27 901094 Locking ring 1 **
28 900708 Shaft sealing ring 1 **
29 800122 Ball bearing compensating disc 1
30 300029 Bearing cap 1
31 800089 O ring 1 **
32 800077 Locking washer 3
33 900312 Allen bolt 3
Item Art. No. Description No.
34 200379 Intermediate cover 1
35 900168 Needle sleeve 2 **
36 900156 Needle sleeve 1 **
37 800083 O ring 1 **
38 800354 O ring 3 **
Wearing parts**
