21
Item
Art. No.
Description
No.
1 201281 Gear, complete 1
2 100080 Gear casing 1
3 900051 Grooved ball bearings 1 **
4 900495 Grooved ball bearings 1 **
5 900670 Interim washer 1
6 400795 Sleeve 1
7 900669 Axial needle rim 2 **
8 900672 Rotor disc 2 **
9 900671 Needle bearing 1 **
10 300670 Support disc 1
11 400011 Brake disc 2 **
12 401308 Floor wheel, complete 1
13 301051 Floor wheel 1
14 400798 Bearing sleeve 1 **
15 400048 Gear change shaft, complete 1
16 800097 O ring 1 **
17 400096 Gear change lever, complete 1
18 800075 Locking disc 1
19 900354 Allen bolt 1
20 900500 Sealing ring 1 **
21 900498 Sealing screw 1
22 302516 Drill spindle, complete 1
23 401964 Wave protection sleeve 1
23 400002 Wave protection sleeve optional 3
24 900110 Adjusting spring 1
25 400796 Bridge sleeve 1
26 300427 Pump wheel 1
27 301052 Pinion shaft 1
28 401310 Loose wheel 1, complete 1
29 301053 Loose wheel 1 1
30 400082 Bearing sleeve 1 1 **
31 400129 Adjusting washer 1
32 800080 Spring ring 1 **
33 900504 Adjusting spring 1
34 900014 Ball 2
35 800165 Bridge spring 1
36 301054 Gear change wheel 1
37 900663 Disc spring 9
38 401965 Compensation slice 1
39 401966 Hexagonal nut 1
40 401311 Loose wheel 2, complete 1
41 301055 Loose wheel 2 1
42 400083 Bearing sleeve 2 1 **
43 900163 Adjusting washer 1
44 900209 Locking ring 1 **
45 300872 Reduction gear shaft 1
46 900127 Adjusting spring 1
47 300754 Reduction gear wheel 1
48 900674 Bush 1
49 801059 O ring 1 **
50 400797 Connection ring 1
51 800760 Locking ring 1 **
52 900673 Shaft seal 1 **
53 900027 Shaft seal 2 **
54 900675 Allen bolt 3
55 900503 Adjusting washer 1
56 901317 O ring 1 **
57 302056 Nut 1
58 901371 Axial needle rim 1
59 402250 Washer 1
60 803128 O ring 1 **
61 803129 O ring 1 **
62 901335 Locking ring 1 **
63 801019 Gear lubricant oil 0,3 l 1 **
Wearing parts
**
