DR FIELD and BRUSH MOWER User Manual

46 TOW-BEHIND DR
®
FIELD and BRUSH MOWER
Parts List - Tow Bar and Remote Control Panel Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 221471 Tow Bar
02 221561 Bushing, 1.75" ID x 2.00" OD x 2.75",
Teflon
03 221491 Washer, 1.00" ID x 1.62" OD, w/Pin Hole
04 150461 Pin, Detent, 1/4" x 2", ZP
05 221531 Pin, Pivot, Tow Bar
06 221541 Pin, Spring, 1/8" x 1", ZP
07 221551 Knob, 3/8"-16, 2.5" Long x 7/8" Wide T
08 126831 Nut, Hex, 3/8"-16, ZP
09 213481 Spring, C, .660" OD x .067" Wire x 2.0"
10 109621 Collar, .50" ID w/Set Screw
11 221461 Pivot, Tow Bar
12 221571 Bushing, .386" ID x .623" OD x 1.915"
13 123371 Bolt, 3/8"-16 x 2.75", HCS, GR5, ZP
14 112391 Washer, Flat, 3/8", USS, ZP
15 110751 Nut, Nylon Lock, 3/8"-16, ZP
16 211551 Pin, Quick Release, 3/8" x 2.5"
17 221581 Pin, Clevis, 1/2" x 9.25"
18 160031 Pin, Hitch Clip, 1/2" to 9/16"
19 213251 Control Panel
20 222231 Switch, Snap-In, Electric Start
21 157201 Key, Ignition Switch
22 191231 Switch, Push/Pull, TPDT
23 222241 Cable & Lever, Throttle, 154" (B&S)
222481 Cable & Lever, Throttle, 170" (Kawasaki)
24 222561 Knob, 3/8"-24, Mount, 1.12" OD
25 114781 Screw, 10-24 x 5/8", Phil Pan, ZP
26 118731 Nut, Nylon Lock, 10-24, ZP
27 222261 Wire Harness, Control
28 222551 Strain Relief, 1/2" Cord
Ref# Part# Description
Items Not Illustrated
191651 Strap, Hook and Loop
188371 Plate, Hitch Tongue Extender
101791 Washer, Flat, 1/2", USS, ZP
(for Extender Plate)
110721 Nut, Nylon Lock, 1/2"-13, ZP
(for Extender Plate)
111441 Bolt, 1/2"-13 x 2", HCS, ZP
(for Extender Plate)
