DR PILOT XT User Manual

CONTACT US AT www.DRpower.com 13
Figure 15
Figure 19
Figure 20
Figure 21
Emptying/Replacing the Collection Bag
The Debris bags can be reused if they are in good condition. Do not reuse if
there are tears or overly wet/soiled areas.
• Replace or empty the Bag as soon as it is full (check by feeling sides of Bag).
Overfilling the bag will cause the vacuuming performance to decrease or stop
completely and could lead to clogging of the discharge tube, snout, or both.
• Empty or remove the Bag completely BEFORE storing the machine to prevent
premature deterioration of the Bag caused from rotting debris and the
possibility of a fire occurring as a result of heat generated by decomposing
debris.
Emptying the Collection Bag:
6. Shut off the Engine and wait for all moving parts come to a complete stop.
7. Lift the Latch Handle and open the Bag Top Cover to its resting position.
(Figure 19).
8. Unwrap the top of the Collection Bag from the Bag Clamping Ring. (Figure
20).
9. Pull the bottom of the bag off the Bag Support Platform. (Figure 21).
10. Either move the machine forward or continue pulling the bag until it is out
from under the handlebar.
11. Empty the Bag for reuse, or fold over the top of the Bag for disposal.

DR PILOT XT Specifications

General

Brand	DR
Model	PILOT XT
Category	Vacuum Cleaner
Language	English
