26 DR
®
LEAF and LAWN VACUUM
Chapter 6: Parts Lists and Schematic Diagrams
Parts List –Handlebar and Bagger Assembly (XT Model)
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 A0000330797 Tube, Exhaust
2 A0000330988 Label, SLV-Instructions
3 A0000330989 Label, SLV-DR Logo Cover
4 333331 Nut, Nylon Lock, Flanged, 3/8-16
5 A0000330841 Bag, Cloth Lid
6 A0000330800 Clamp, Bag Top
7 276761 Pin, Cotter, 3/32″ X 1/2″, ZP
8 A0000330877 Screw, RHDS,-8-18 X .5″, ZP
9 333311 Nut, Nylon Lock, Flanged, 1/4-20
10 A0000330818 Platform, Bag Support
11 A0000330819 Handlebar, Lower
12 A0000330820 Handlebar, Upper
13 A0000032880 Adjuster, Handlebar, 1.25″ Tube
14 A0000330861 Adjuster, Handlebar, 1.00″ Tube
15 143931 Spring, C, .720″ OD .063″ Wire
0.63″, ZP
16 A0000222872 Bolt, Carriage, -5/16-18 X 3-1/2″, ZP
17 311121 Knob, 2.25″ Dia, 516-18 Insert
18 123361 Bolt, HCS, 5/16-18 X 1-1/4″, GR5,
ZP
19 333321 Nut, Nylon Lock, Flanged, 5/16-18
20 112411 Washer, Flat, 5/16″, USS
21 A0000655096 Recoil Holder, Wire Form
Ref# Part# Description
22 350381 Nut, Nylon Lock, Flange, 10-24, ZP
23 A0000330878 Screw, RHTF,-10-14 X .75″, ZP
24 A0000330874 Bolt, Barrel Male, -10-24 X 5/16″,
ZP
25 A0000330875 Bolt, Barrel Female, 10-24 X 1/4″,
ZP
26 A0000330926 Ring, Bag Clamping
27 A0000330822 Clamp, Lid Hinge
28 A0000330896 Cover w/Labels, Bag Top
29 A0000330949 Latch, Body
30 A0000330950 Handle, Latch
31 A0000330852 Bracket, OPC Contact
32 A0000330853 Bracket, Switch
33 A0000330799 Seal, Bag Top
34 A0000330825 Tube, Chute
35 A0000330838 Wire Harness, OPC
36 A0000330881 Clamp, Hose Bridge, 6″
37 A0000330868 Bolt, Hex, Flanged, 5/16-18 X 1/2″,
ZP
38 A0001435741 Rack-Bag
39 A0000330900 Pin, Clevis, 3/8″ X 1″
Not Shown
A0000330872 Bags, Paper, 5 Pack
To Next Page
