28 DR
®
LEAF and LAWN VACUUM
Parts List – Drive Assembly (XT Model)
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 A0000330802 Frame
2 A0000331003 Housing, Impeller
3 A0000330904 Shield, Deflector
4 A0000330806 Impeller, without Knife
5 A0000330860 Panel, Back
6 A0000330914 Plate, Bear Claw
7 A0000330915 Plate, Front Axle Mount
8 A0000330813 Mount, Front Wheel
9 A0000330829 Plug, Snout
10 A0000330812 Axle, Front
11 A0000330811 Spacer, Engine, Push
12 A0000330823 Plate, Left, Rear Axle
A0000330824 Plate, Right, Rear Axle
13 A0000330858 Bushing, Axle
14 396181 Knob, Tapered, Plastic
15 A0000330807 Snout
16 A0000330894 Engine w/Labels, DR, 7.6GTQ,
M/S, RV170
Ref# Part# Description
17 A0000330843 Wheel, 8″
18 A0000330831 Wheel, 10″
19 A0000330832 Cover, Wheel, 10″
20 A0000330844 Cover, Wheel, 8″
21 A0001427178 Cover, Push
22 333331 Nut, Nylon Lock, Flanged, 3/8-16
23 333311 Nut, Nylon Lock, Flanged, 1/4-20
24 A0000330809 Cover, Chipper
25 333321 Nut, Nylon Lock, Flanged, 5/16-18
26 A0000330868 Bolt, Hex Flanged, 5/16-18 X 1/2″,
ZP
27 188821 Bolt, HCS, 3/8-24 X 2 1/4″, GR8, ZP
28 180811 Washer, Lock Split, 3/8″
29 A0000330876 Bolt, Hex, 1/4-20 X 8.25″, ZP
30 A0000330816 Lever, Height Adjust
To Next Page
