32 DR
®
LEAF and LAWN VACUUM
Parts List – Drive Assembly (XTSP Model)
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 A0000330802 Frame
2 A0000331003 Housing, Impeller
3 A0000330904 Shield, Deflector
4 A0000330805 Impeller, with Knife
5 A0000330860 Panel, Back
6 A0000330914 Plate, Bear Claw
7 A0000330915 Plate, Front Axle Mount
8 A0000330813 Mount, Front Wheel
9 A0000330829 Plug, Snout
10 A0000330812 Axle, Front
11 A0000330810 Spacer, Engine, SP
12 A0000330823 Plate, Left, Rear Axle
A0000330824 Plate, Right, Rear Axle
13 A0000330858 Bushing, Axle
14 396181 Knob, Tapered, Plastic
15 A0000330807 Snout
16 A0000330895 Engine w/Labels, DR, 7.6GTQ, E/S,
RV170
17 A0000330843 Wheel, 8″
18 A0000330831 Wheel, 10″
19 A0000330832 Cover, Wheel, 10″
20 A0000330844 Cover, Wheel, 8″
21 422601 Cover, Inner, 10″ Wheel
22 A0000330856 Shaft, Pulley Riser
23 A0000330854 Bracket, Transmission
24 A0000330863 Cover, Belt
Ref# Part# Description
25 A0000330855 Pulley, 3L V-Belt, 3.0″ OD, .38″
Shaft
26 A0000330862 Belt, Linked, 3L
27 422691 Gear, LH, SP
28 A0000330845 Transmission
29 A0000923957 Ring, Retaining, 12mm
30 A0000330898 Pin, 5mm Dia X 22mm Long
31 333331 Nut, Nylon Lock, Flanged, 3/8-16
32 A0000330883 Bearing, Flanged, 5/8″ ID-1-3/8″
OD
33 333311 Nut, Nylon Lock, Flanged, 1/4-20
34 A0000330880 Pin, Roll, 5mm X 18mm, Plain35
35 A0000330808 Hopper, Chipper
36 333321 Nut, Nylon Lock, Flanged, 5/16-18
37 A0000330868 Bolt, Hex Flanged, 5/16-18 X 1/2″,
ZP
38 188821 Bolt, HCS, 3/8-24 X 2 1/4″, GR8, ZP
39 180811 Washer, Lock Split, 3/8″
40 A0000330876 Bolt, Hex, 1/4-20 X 8.25″, ZP
41 247491 Battery, 2.3Ah, 12V
42 143851 Clamp, Battery
43 143861 Pad, Battery, 1.38″ X 7.0″
44 A0000330839 Wire Harness, ES
45 114681 Bolt, HCS, 1/4-20 X 1 1/4″, GR5, ZP
46 A0000330816 Lever, Height Adjust
Not Shown
A0000330992 Label, SLV, DR Logo, 3″
A0000330991 Label, SLV, Pilot XTSP
137581 Label, Check Oil, 2.75″ X .63″
