PRO XL-SP STUMP GRINDER
Throttle
Lever
“Start” Key Switch
Figure 2
Maintenance
Meter
(optional
Operator
Presence
Lever
Brake Lever
Pneumati
c Tir
Oil
Carbide
Teeth
Belt
Guard
Gas Fill
Battery
REAR VIEW
Oil
Fill/Check
Starter Cord
Traction Drive
Leve
r
Cutter Head
Shroud
Chapter 2: Setting Up The DR PRO XL-SP STUMP GRINDER
It may be helpful to familiarize yourself with the controls and features of your DR PRO XL-SP STUMP GRINDER as shown in
Figure 2 before beginning these procedures. If you have any questions at all, please feel free to contact us at www.DRpower.com.
DR PRO XL-SP STUMP GRINDER Controls and Features
Choke Lever
Fuel
Shut-off
