5664.500/800 Evita 4/Evita 2 dura 02/98 Repair Instructions Page 5
Dräger Medizintechnik
D
15.2.3 X5 Connector on the Frontpanel PCB to the Control Knob ...............74
15.2.4 X7 Connector on the Frontpanel PCB to the display............................74
15.2.5 X9 Connector on the Frontpanel PCB to the DC/AC Transformer...74
15.3 Front Panel PCB Repair Information ........................................................................74
15.4 Frontpanel PCB Component Layout Diagram ....................................................... 75
16 Pneumatics Controller PCB 76
16.1 Power Supply to the Pneumatics Controller PCB ................................................ 76
16.2 Connector Pin Assignment of the Pneumatics Controller PCB ........................ 76
16.3 Replacing the Pneumatics Controller PCB ............................................................ 84
16.4 Tests possible in DS mode ......................................................................................... 85
16.4.1 Diagnosis mode............................................................................................ 85
16.4.2 External DS mode using PC...................................................................... 85
17 HPSV Controller PCB 86
17.1 Power Supply to the HPSV Controller PCB .......................................................... 86
17.2 Replacing the HPSV Controller O
2
/AIR PCB ....................................................... 88
17.3 Notes Relating to Trouble Shooting ......................................................................... 89
17.4 Tests possible in DS mode ......................................................................................... 89
17.4.1 Diagnosis mode............................................................................................ 89
17.4.2 External DS mode using PC...................................................................... 89
