3363923 (A3-D-P) Page 3 of 3
5.2 Cleaning and disinfecting
CAUTION
Do not exceed 60 °C for drying, and remove components from the
drying facility immediately when dry. Drying time in a heated dryer
must not exceed 30 minutes.
Do not immerse pneumatic or electronic components in cleaning
solutions or water.
If water is trapped and then freezes inside the pneumatic system
of the breathing apparatus (such as the lung demand valve),
operation will be impaired. Prevent any liquid from entering, and
thoroughly dry the breathing apparatus after cleaning to prevent
this from occurring.
For information about suitable cleaning and disinfecting agents
and their specifications refer to document 9100081 on
www.draeger.com/IFU.
Refer also to the Instructions for Use for the lung demand valve, face mask
and other associated equipment.
● Use only clean lint-free cloths
1. Clean the breathing apparatus manually using a cloth moistened with
cleaning solution to remove excess dirt.
2. Apply disinfecting solution to all internal and external surfaces.
3. Rinse all components thoroughly with clean water to remove all
cleaning and disinfecting agents.
4. Dry all components using a dry cloth, in a heated dryer or in air.
5. Contact service personnel or Dräger if disassembly of the harness,
space frame or pneumatic components is required.
5.2.1 Carrying harness – Thorough cleaning
CAUTION
Thorough cleaning may only be carried out by suitably trained
personnel. Disassembly of the breathing apparatus by untrained
personnel is not permitted and may damage the apparatus.
1. Remove the harness from the carrying system and clean using one of
the following methods:
a. Clean manually in a bath containing recommended cleaning or
disinfecting agents.
b. Machine wash (at 30 °C) using a suitable cleaning agent.
2. Rinse the harness thoroughly with clean water to remove all cleaning
and disinfecting agents.
3. Dry all components including internal parts.
5.3 Maintenance work
5.3.1 Air cylinder charging
WARNING
The air supply shall meet the requirements for breathable air
according to EN12021.
Refer to the instructions supplied with the cylinder and the charging
apparatus for recharging a compressed air cylinder.
6 Storage
6.1 Storage preparation
● Extend the shoulder straps, waist belt and the straps of the face mask.
● For storage, place the face mask in a protective bag (we recommend
contacting Dräger for supply of a suitable bag).
● Route rubber hoses in such a way that the bend radius is not too acute
and the hose is not stretched, compressed or twisted.
6.2 Storage conditions
● Store the equipment between -15 °C and +25 °C. Ensure that the
environment is dry, free from dust and dirt, and does not subject the
equipment to wear or damage due to abrasion. Do not store the
equipment in direct sunlight.
● Fix the breathing apparatus securely to any raised mounting point to
prevent it from falling.
7 Technical data
8 Order list
High-pressure connection Standard G5/8″ as per EN 144-2
(200 bar or 300 bar)
Compressed air cylinders (single
cylinder configuration)
4 litre to 9 litre (200 bar or 300 bar),
steel or composite materials
Compressed air cylinders (twin
cylinder configuration)
4 litre (200 bar), steel;
6 litre to 6.8 litre (300 bar),
composite materials
Whistle warning Initial activation: 60 bar to 50 bar
Medium pressure 6 bar to 9 bar
Operating temperature EN137 temperature range
Description Quantity Order code
Dow Corning
®
Molykote
®
111
100 grams 3331247
