The DRAKEFOR DKF-INFINITY is a luxury aesthetic device designed and developed by doctors and engineers from DRAKEFOR & CO. It is an innovative and revolutionary device aimed at effectively combating two of the most common aesthetic concerns: cellulite and aging.

Function Description:

The DKF-INFINITY device integrates multiple functions for comprehensive skin care:

3 MHz Ultrasounds: These acoustic waves, imperceptible to the human ear, are an ideal solution for various beauty problems due to their triple impact efficacy. The 3 MHz ultrasounds generate intense vibrations that cause thermal, mechanical, and cavitational effects in the skin.
1. They can produce pressure variations in the interstitial fluids between fat cells (adipocytes or lipocytes), breaking the fragile membranes of cellulite cells. This releases fat in emulsion, which is then redirected to lymphatic channels for physiological elimination.
2. Ultrasounds penetrate deeply into the skin, generating internal heat that stimulates cells responsible for skin firmness, such as collagen and elastin, leading to a more youthful appearance.
3. Ultrasounds facilitate the penetration of creams into the skin, enhancing their effectiveness.
RGB Phototherapy (Red and Blue Light): This technique uses light with different wavelengths, each having distinct effects on the skin. The energy from high-efficiency LEDs stimulates cellular responses beneficial for treating photoaging, acne, and hyperpigmentation.
- Red Light: Ideal for all skin types, it stimulates cells, increases blood circulation, and promotes collagen production and tightening of fibers, resulting in firmer and more elastic skin.
- Blue Light: Penetrating 0.5mm, it calms and eliminates skin eruptions, reduces acne, and is recommended for sensitive, oily, or breakout-prone skin. It provides a calming and astringent effect.
Galvanic Currents (Positive and Negative Ions):
- Positive Ions (ION+): These expel stubborn dirt from pores, promoting oxygenation and tightening of the pores.
- Negative Ions (ION-): These introduce deep nourishment into the skin. Creams applied manually only reach the external epidermal layer, but negative ions ensure deep cellular nourishment, maximizing the benefits of skincare cosmetics.
Relax Function (Massage): The device includes an ultrasonic massage function with intense continuous or discontinuous vibrations, providing a very relaxing effect.

Visible Results and Goals:

Ultrasounds:

Elimination of cellulite, localized fat, and acne-causing bacteria.
Helps prevent and soften facial wrinkles and expression lines.
Improves the appearance of dark circles and under-eye bags.
Facilitates the absorption of creams, tonics, and gels into the skin.
Acts as a firming and muscle invigorating agent, improving elasticity for smoother, firmer skin.
Increases blood flow and cellular oxygenation.
Stimulates the creation of vitamin D12 and collagen.
Softens skin blemishes.
Deep cleansing of pores.
Reduces pores and acne scars.
Rejuvenation.

Phototherapy:

Increases blood flow and cellular oxygenation.
Eliminates acne-causing bacteria.
Stimulates the creation of vitamin D12 and collagen.
Helps in the disappearance of skin blemishes.

Positive Ions:

Deep cleansing of pores.

Negative Ions:

Deep nourishment in conjunction with ultrasounds.
Adsorption and absorption of active ingredients from creams into cell membranes.
Systematic rejuvenation.

Important Technical Specifications:

Model: DKF-INFINITY
Weight: 165 g
Size: Height: 60 mm / Length: 190 mm / Width: 50 mm
Working Environment: 5-40°C
Power Supply:
- Input: AC 100-240V 50/60 Hz
- Output: DC 5.0 V - 0.4A (Rechargeable Unit)
Li-ion Battery Volume: 1150 mAh
Nano Photon LED Wavelengths:
- Red LED: 625+-3nm
- Green LED: 525+-3nm
- Blue LED: 465+-3nm

Usage Features:

Operation:
1. Connect the transformer to the device and then to a power outlet.
2. Press the POWER button to turn on the device; the blue backlight will illuminate. Press again to turn off.
3. Press the MODE button repeatedly to cycle through functions; desired functions will flicker. Once selected, press SHIFT to adjust intensity, then CONFIRM.
4. Multiple functions can be selected simultaneously (recommended).
Recommended Use:
- Not recommended for daily prolonged use. Maximum 20 minutes per day (face area: 3-5 minutes; body area: no more than 10 minutes per zone).
- Wear the included protective glasses as LEDs emit electromagnetic wavelengths between 480 and 640 nanometers.
- For facial treatments, thoroughly clean the skin first (preferably with an ultrasonic facial brush and cleansing cream). Apply nutritive, toning, or anti-wrinkle cream and gently slide the device in circular movements, avoiding eyes, lips, and mucous membranes.
- For body treatments, use a conductive gel, slimming cream, or anti-cellulite cream. Place the device head on the cream and massage with circular movements for five to ten minutes per area.
- Do not leave the head on the same area for more than 5 seconds without moving.
- After the session, manually massage the treated area for a few seconds.
- It is recommended to apply the ULTRASONIC, IONIC, RELAX, and PHOTONIC functions together, always with an active substance like cream, gel, or tonic.
Safety Mechanisms:
- The device has a safety mechanism that automatically turns off if the temperature becomes too high.
- It includes a timer control; if the device is in standby (whether in use or not), it will automatically turn off. To reuse, restart the machine.
- Do not use the machine for more than 30 consecutive minutes.
- To verify ultrasonic function, drop a few water drops on the metallic surface; if it "boils," the machine is working correctly. Remember to turn off and unplug after treatment.
- Ideal usage time is 15 to 20 minutes per daily session.

Maintenance Features:

Cleaning:
- After use, clean the device delicately. A soft cloth is recommended to avoid scratches on the head.
- Do not use water or chemical substances to clean the product, as this could cause malfunction and shorten its lifespan.
Storage:
- Store the product in a dry place and do not use it underwater to prevent corrosion or short circuits of electronic components.
- Do not store near heat sources, as this can cause malfunction, shorten product life, or damage plastic components.
- Keep out of reach of children.
General:
- Use only the electric adapter included in the box. Incompatible adapters can cause malfunction and invalidate the warranty.
- Pull the plug (never the cable) to unplug the machine.
- Organize all cables neatly; do not roll, break, or damage their surface.
- Do not drop or subject the product to impacts, as this can cause component breakage.
- Never attempt to disassemble the product yourself. Maintenance and repair must be performed by professional technicians.

Drakefor DKF-INFINITY - Page 15
