Vigor2860 Series User’s Guide
165
Each item is explained as follows:
Item Description
Index
Display the number of the profile.
Service Name
Display the description of the specific network service.
WAN Interface
Display the WAN IP address used by the profile.
Protocol
Display the transport layer protocol (TCP or UDP).
Public Port
Display the port number which will be redirected to the
specified Private IP and Port of the internal host.
Private IP
Display the IP address of the internal host providing the
service.
Status
Display if the profile is enabled (v) or not (x).
Press any number under Index to access into next page for configuring port redirection.
Available settings are explained as follows:
Item Description
Enable
Check this box to enable such port redirection setting.
Mode
Two options (Single and Range) are provided here for you
to choose. To set a range for the specific service, select
Range. In Range mode, if the public port (start port and end
port) and the starting IP of private IP had been entered, the
system will calculate and display the ending IP of private IP
automatically.
Service Name
Enter the description of the specific network service.
Protocol
Select the transport layer protocol (TCP or UDP).
