Dream Maker Spas Crossover Collection - Page 9

9
DIP SETTINGS 564413-04
MAIN POWER TO SYSTEM MUST BE TURNED OFF BEFORE ADJUSTING DIP
SWITCHES
TEST MODE OFF
1
TEST MODE ON
N/A
2
N/A
DUPLEX PANEL
3
MINI PANEL
N/A MUST BE OFF
4
N/A MUST BE OFF
SEE PUMP TABLE
5
SEE PUMP TABLE
60HZ OPERATION
6
50HZ OPERATION
STD, ECON, SLEEP ALLOWED
7
STANDARD MODE ONLY
DEGREES FAHRENHEIT
8
DEGREES CELSIUS
SEE PUMP TABLE
9
SEE PUMP TABLE
HIGH AMP – HEAT W/P1 HI
24 AMP RATING (32 AMP CIRCUIT)
10
LOW AMP – NO HEAT W/P1 HI
16 AMP RATING (20 AMP CICUIT)
PUMP TIMEOUTS TABLE
Switch 5
Switch 9
Low speed
High speed
Off
Off
2 Hours
15 Minutes
On
off
2 Hours
30 Minutes
Off
On
15 Minutes
15 Minutes
on
On
30 Minutes
30 Minutes
DIP
SETTINGS
