Rev 2.1
Shower Door Installation
1. Measure the distance between two finished
walls.
This distance is marked as “W”.
See Fig. 1 for details.
Fig. 1
2. Your Guide rail (03) has been precut for the
installation between the walls with a distance of
60”.
If W=60”, then it is unnecessary to cut the
Guide rail and you can continue to Step#3.
If W<60”, then you will need to cut the Guide
rail from the end which is farthest from the
Glass bracket (07) holes.
The length to cut off will be “L”:
L = (60”−W).
See Fig. 2 for details.
Fig. 2
3. Your Threshold (15) has been precut for
the installation between the walls with a
distance of 60”.
If W=60”, then it is not necessary to cut the
threshold.
To Next Page
