Rev 2.1
Fig. 12
11. Adjust the fasteners on both top Rollers (04) to ensure that the
bottom edge of the Glass door (05) does not touch the bottom of
the guide block. Tighten the fasteners.
See Fig. 13 for details.
Fig. 13
12. Refer to Step 3 to cut the Threshold
cover (14) if it’s necessary.
Push the Threshold cover into the
Threshold (15) groove when the door is
in the opened position.
Install the Handle (06) to the Glass
door (05).
See Fig. 14 for details.
Fig. 14
To Next Page
