“INFINITY-Z” Rev.2 Ver.4 08/2013
6
4. Secure the bottom Guide rail (03) to the Glass profiles (01) with
the Round head screws ST4.2x25 (10).
See Fig. 5 for details.
Fig. 5
5. Slide the Stationary glass (05) fully into the groove of the Glass
profile (01), and then secure it to the bottom Guide rail (03) with
the Glass holder (16).
See Fig. 6 for details.
Fig. 6
