04 05
3.
4.
Carefully rotate the f
oundation
over so it is resting on its legs.
Install legs and tighten by hand.
Mattress Retainer Block
AC Power Cord
DC Power Cord
Power Supply
AC Power Source
Connect the DC power cord to the power supply, uncoil the AC power cord
and then connect it to the AC power source .
Connect the connectors as illustrated.
DONE!
+
Insert batteries into the wireless remote.
6.
7.
5.
Slide the left side of the mattress retainer
bar into the bracket. Pull the retainer bar to
the opposite bracket and secure the right side.
2
1
2.
Remove the foundation from the box. Make sure the floor is clean. Flat the foundation.
To Next Page
