6
FLAME LENGTH AND
TEMPERATURE ADJUSTMENT
Move the flame control lever forward to increase the flame
length and temperature, or backward to decrease the flame
length and temperature.
When using an open flame, the Dremel VersaFlame is at the
desired temperature immediately after ignition.
Please allow ± 25 seconds of heat-up time for the soldering tip.
USING THE ACCESSORIES
!
WARNING
ALWAYS SWITCH OFF THE TOOL AND
ALLOW IT TO FULLY COOL DOWN
BEFORE ATTACHING OR REMOVING ACCESSORIES.
The Dremel VersaFlame is delivered with a catalyst, a soldering
tip, a flame extension piece and a deflector.
CATALYST (Figure 1 part 2)
The catalyst generates hot air of 680°C: Used for melting
plastics and other heat-sensitive materials.
1. Slide the narrow part of the catalyst into the burner. Make
sure the slot of the catalyst is aligned with the white
indicator mark. See Figure 5.
2. To remove the catalyst, slide it out of the burner.
SOLDERING TIP (Figure 1 part 1)
The soldering tip (to be used on the catalyst): used for regular
soldering activities, using soldering tin.
1. Screw the soldering tip in clockwise direction onto
the catalyst. Secure the tip using the 7 mm wrench
(provided). See Figure 6.
2. To remove the soldering tip, use the 7 mm wrench to
unscrew the tip in counter-clockwise direction.
FLAME EXTENSION PIECE (Figure 1 part 12)
The flame extension piece generates hot air of approx. 1000°C:
Used for heating larger surfaces.
1. Loosen the screw to fit the front tip of VersaFlame
(screwdriver not included). See Figure 7.
DEFLECTOR (Figure 1 part 13)
To be used with the flame extension piece. See Figure 7.
MAINTENANCE
CLEANING THE TOOL
!
WARNING
ALWAYS SWITCH OFF THE TOOL AND
ALLOW IT TO FULLY COOL DOWN
BEFORE CLEANING.
1. Clean the exterior of the tool with a clean cloth. If
necessary, use a damp cloth with a small amount of
neutral detergent.
2. After soldering or in case of excess solder on the
soldering tip, wipe the tip on a soldering sponge
soaked in some water when it is still hot.
3. Never clean the soldering tip with sandpaper as this
reduces its lifetime.
SERVICE AND WARRANTY
This DREMEL product is guaranteed in accordance with
statutory/country-specific regulations; damage due to normal
wear and tear, overload or improper handling will not be
covered by the guarantee.
In case of a complaint, send the tool undismantled together with
proof of purchase to your dealer.
CONTACT DREMEL
For more information on the Dremel assortment, support and
hotline, go to www.dremel.com.
取扱説明書
使用されている記号
本書に記載の内容をよくお読みく
ださい
安全装置を使用してください。
必ず保護メガネを着用してください。
Dremel VersaFlameを使用する前に必ず本書をお読み
になり、しっかりと理解してください。.
!
本書に記載の内容をすべて
お読みください。
以下の内容にしたがわない場合、火災や重症につなが
るおそれがあります。
本書は保管しておいてください。
作業領域
a. 作業領域を清潔かつ明るい状態に保ってくださ
い。
散らかっている場合や照明が十分でない場
合、事故につながるおそれがあります。
JP
