electric shock. Damaging a gas line can lead to explosion.
Penetrating a water line causes property damage or may
cause an electric shock.
d. When working with the machine, always hold it firmly
with both hands and provide for a secure stance. The
power tool is guided more secure with both hands.
e. Secure the workpiece. A workpiece clamped with clamping
devices or in a vice is held more secure than by hand.
f. Keep your workplace clean. Blends of materials are
particularly dangerous. Dust from light alloys can burn or
explode.
g. Wear protective gloves when changing application tools/
accessories. Application tools/accessories become hot after
prolonged usage.
h. Do not treat the surface to be worked with solvent-
containing fluids. Materials being warmed up by the
scraping can cause toxic vapours to develop.
i. Exercise extreme caution when handling the scraper. The
accessory is very sharp; danger of injury.
!
WARNING
DO NOT WORK WITH MATERIALS
CONTAINING ASBESTOS (ASBESTOS IS
CONSIDERED CARCINOGENIC).
!
WARNING
TAKE PROTECTIVE MEASURES WHEN
DURING WORK DUST CAN DEVELOP
THAT IS HARMFUL TO ONE’S HEALTH, COMBUSTIBLE OR
EXPLOSIVE (SOME DUSTS ARE CONSIDERED CARCINOGENIC);
WEAR A DUST MASK AND WORK WITH DUST/ CHIP
EXTRACTION WHEN CONNECTABLE.
ENVIRONMENT
DISPOSAL
The machine, accessories and packaging should be sorted for
environmental-friendly recycling.
ONLY FOR EC COUNTRIES
Do not dispose of power tools into household waste!
According the European Guideline 2002/96/EC for
Waste Electrical and Electronic Equipment and its
implementation into national right, power tools that are
no longer usable must be collected separately and
disposed of in an environmentally correct manner.
SPECIFICATIONS
GENERAL SPECIFICATIONS
Voltage Rating 230 V, 50 Hz
Rated Power 130W
Rated Speed 33 000 RPM
Collet Capacity 0.8mm, 1.6mm, 2.4mm, 3.2mm
Class II construction Double insulated construction tools
EXTENSION CORDS
Use completely unrolled and safe extension cords with a capacity
of 5 Amps.
MOTOR SPECIFICATIONS
This multitool utilizes a variable high speed motor. It is wired for
operation on 230 V, 50 Hz. Always check that the supply voltage
is the same as the voltage indicated on the nameplate of the tool.
ASSEMBLY
ALWAYS UNPLUG MULTITOOL BEFORE CHANGING
ACCESSORIES, CHANGING COLLETS, OR SERVICING THE
TOOL.
GENERAL
The Dremel multitool is a high quality precision tool that can be
used to perform detailed and intricate tasks. The wide range of
Dremel accessories and attachments allow you to perform a large
variety of tasks. These include tasks such as sanding, carving and
engraving and routing, cutting, cleaning and polishing.
PICTURE 1
A. Collet nut
B. Collet
C. EZ Twist™ integrated wrench/nose cap
D. Shaft lock button
E. On/Off switch
F. Hanger
G. Cord
H. Ventilation openings
I. Brush cover (one on each side)
J. Ventilation openings
COLLETS
The Dremel accessories available for the multitool come
with various shank sizes. Four size collets are available to
accommodate the different shank sizes. Collet sizes are identified
by the rings on the back of the collet.
PICTURE 2
K. 3.2 mm Collet without ring (480)
L. 2.4 mm Collet with three rings (481)
M. 1.6 mm Collet with two rings (482)
N. 0.8 mm Collet with one ring (483)
NOTE: Some multitool kits may not include all four collet sizes.
Collets are available separately.
Always use the collet which matches the shank size of the
accessory you plan to use. Do not force a larger diameter shank
into a smaller collet.
22
