Battery tools are always in an operative condition. Be aware of the
possible hazards.
SAVE THESE INSTRUCTIONS
-6-
Functional Description and Specifications
Dremel HSGP-01 Glue Pen
Cordless Glue Pen
Model number . . . . . . . . . . . . .HSGP-01
Voltage rating . . . . . . . . . . . . .3.6V / 4V Max
Heat-up time . . . . . . . . . . . . . .approx. 15 s
Gluing temperature . . . . . . . . .approx. 338 °F (170 °C)
Glue stick diameter . . . . . . . . .0.28" (7 mm)
Allowed ambient temperature
– during charging . . . . . . . . . .41...104 °F (+5...+40 °C)
– during operation/storage . . .41...113 °F (+5...+45 °C)
Power Adapter
Model number . . . . . . . . . . . . .510
Voltage rating (input) . . . . . . .120V 60 Hz
Amperage rating (output) . . . .1A
Battery
Chemistry . . . . . . . . . . . . . . . .Li-ion
Capacity . . . . . . . . . . . . . . . . . .1.5 Ah
Charge time . . . . . . . . . . . . . . .approx. 3–4 Hrs.
Operating time . . . . . . . . . . . .approx. 30 min
1 Nozzle
2 Silicone cap
3 Feed trigger
4 On/Off button
5 LED indicator
6 Glue stick opening
7 Micro USB port
8 Glue stick
9 USB cable
10 Power adapter
Fig. 1
