Page 7For technical questions, please call 1-800-444-3353.Item 69651
Specifications
Charger Input Rating 120V~ / 60Hz
Battery Rating 18V / 1300mAh
Battery Type NiCd
Charging Time 3-5 hours
No Load Speed 0-900 RPM
Settings
20 Torque Settings
1 Drill Setting
Chuck Capacity 3/8" Keyless
Setup - Before Use
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Note: For additional information regarding the parts listed in the following pages,
refer to Parts List and Diagram on page 11.
Functions
Green LED
Red LED
Charger
Figure A
Keyless Chuck
Direction Switch
Work Light
Trigger
Torque Adjustment Ring
Battery Button
Battery Pack
SAFETYOPERATIONMAINTENANCE SETUP
