Drive Medical GmbH & Co. KG | Version: 29.06.2016 User Manual Children Walking Aid Nimbo
Unfold and assembling
The Nimbo has a foldable aluminium-pipe frame and
is height adjustable in the wheels. In order to open up
you lay the Nimbo on the ground, stick it possibly in
the middle of the front frame and open up the frame.
Please, note while opening that the feather clips en-
gage in the telescope pipes always properly (Audible
click !).
For assembling you must only insert the Front- and
Back wheels.
Wheel lock front
In order to interlock the front wheels adjust them
straight (1), then pull the Locking pin upwards (2) and
turn him around 90 ° (3) until it locks in the hinged
plate (4). To reset the interlock repeat the process.
1
2
3
4



Hight adjustment of the wheels
The front- and the back wheels are height-adjustable
in 8 steps. To adjust press the spring snap (arrow) and
shift the pipe as desired. Make sure that the spring
snap always engages properly!
Front wheel Rear Wheel
Non-return lock
1 2
1 Non-return lock
activated
2 Non-return lock
deactivated
Folding
To fold the kids walking aid press the spring snap
(arrow) in the cross tube and fold it antipodal to the
unfolding.
