Assembly Instructions
1. Remove the contents from the carton.
2. Insert the front tiller in to the front of the
frame (figure 1).
3. Once the tiller is in place and the handles
are aligned correctly with the wheels,
tighten the screw (figure 2) using an allen
key by turning clockwise.
4. Straighten the tiller to the upright position.
Slide the second screw into the receptacle
(figure 3).
5. Secure the screw and tiller in place by
pushing the locking handle against the side of
the tiller (figure 4).
6. Insert the seat post in to the seat
receptacle. Follow the instructions overleaf to
install the seat.
