DS18 ZXI-44 User Manual

OWNER'S MANUAL
ZXI
COAXIAL SPEAKERS
ZXI-44 ZXI-354 ZXI-464
SPECIFICATIONS
Nominal Diameter
Nominal Impedance
RMS Power Handling
MAX Power Handling
Sensitivity (1w/1m)
Frequency Response
Recommended HI Pass Crossover
Speaker Type
MOTOR
Voice Coil Diameter
Voice Coil Former Material
Winding Material
Cone Material
Surround Material
Basket Material
Magnet Material
Magnet Weight
TWEETER
Nominal Diameter
Voice Coil Diameter
Voice Coil Former Material
Winding Material
Diaphragm Material
Magnet Material
Magnet Weight
THIELE & SMALL PARAMETERS
Equivalent Volume
Excursion (one way)
Free Air Resonance
Mechanical Factor
Electrical Factor
Total Factor
Mechanical Mass
Mechanical Compliance
BL Factor
Voice Coil Inductance
Cone Area
DC Resistance
Mechanical Mass w/o air
MEASUREMENTS
Overall Diameter
Overall Depth
Front Mount Baffle Cutout
Mouting Depth
Motor Diameter
4”
4 ohm
50 Watts
150 Watts
88dB
80Hz-20Khz
100Hz
2-Way
1” / 25.5mm
KSV
EISV
Glass fiber
Rubber
Steel
Barium Ferrite
10.9 oz / 310g
1" (25.4mm)
0.8"(ø20.4mm)
KSV
EISVM
PEI
Neodymium
0.3 oz / 8.5g
1.59L
2.3mm
95Hz
9.00
0.8
0.74
8.47g
364.9mm/N
4.583
216mH
55.4cm2
3.5 ohm
8.0g
3.94“ / 100mm
2.80” / 71mm
3.66” / 93mm
2.20” / 56mm
3.31” / 84mm
Vas
Xmax
Fs
Qms
Qes
Qts
Mms
Cms
BL
Le
Sd
Re
Mmd
3.5”
4 ohm
40W
120W
86dB
120Hz-20KHz
140Hz
Full Range
1”
1” / 25.5mm
KSV
EISV
Glass fiber
Rubber
Steel
Barium Ferrite
10.9oz / 310g
-
-
-
-
-
-
-
0.55L
1.4mm
140Hz
7.08
1.37
1.15
3.2g
402mm/N
2.938
169mH
32cm2
4.2 ohm
3.0g
3.50” / 89mm
1.65” / 42mm
2.80” / 71mm
1.49” / 37.8mm
2.36” / 60mm
4x6”
4 ohm
60 Watts
180 Watts
87dB
80Hz-20KHz
100Hz
2-Way
1” / 25.5mm
KSV
EISV
Glass fiber
Rubber
Steel
Barium Ferrite
10.9 oz / 310g
1" (25.4mm)
0.8"(ø20.4mm)
KSV
EISVM
PEI
Neodymium
0.3 oz / 8.5g
1.989L
2.3mm
77Hz
5.97
1.15
0.97
9.79g
232mm/N
4.44
216mH
77.7cm2
3.5 ohm
9g
3.82x5.94” / 97x151mm
2.80” / 71mm
3.46x5.51” / 87.8x140mm
2.05” / 52mm
3.31” / 84mm
