PC9155 Panel Controlled Call Routing
Backup (triple‐path)
Panel section [383] – Options [2],[3] and [4] enabled
Panel section [380], Option [6] disabled
Redundant (triple‐path)
Panel sections [351] – [376] Options enabled
Alternate (triple‐path)
Panel section [380] – Option [6] enabled
Required Programming
Panel Sections [301], [302],[303] and [305]
• Phone #: Phone number of the receiver
• DCBB: Ethernet Receiver 1
• DCCC: Ethernet Receiver 2
• DCDD: GPRS Receiver 1
• DCEE: GPRS Receiver 2
PC9155 Panel Controlled Call Routing
–Backup: Panel Section [383] – Options [2],[3] and [4] enabled
DCDD[305]
DCCC[303]
DCBB[302]
1‐800‐xxxxxxx[301]
DCDD[305]
DCCC[303]
DCBB[302]
1‐800‐xxxxxxx[301]
Phone Line Receiver 1
IP Receiver 1
IP Receiver 2
IP Receiver 3
Phone Line path
Ethernet Receiver 1
Ethernet Receiver 2
GPRS Receiver 1
TX 1
Tx 1 5 failures, Tx2
Tx 2 5 failures, Tx3
Tx 3 5 failures, Tx4
Example
