PowerSeries Neo Installation Guide
Trouble 08 – RF Delinquency Trouble:
[01] Zone 001 - 128 RF Delinquency: No response from a wireless zone for 13
minutes. This trouble prevents arming until acknowledged or cleared using [*][2].
[02] Keypad 01 - 16 RF Delinquency: No response from a wireless keypad for 13
minutes.
[03] Siren 01 - 16 RF Delinquency: No response from a wireless siren for 13 minutes.
[04] Repeater 01 - 16 RF Delinquency: No response from a wireless repeater for 13
minutes.
Trouble 09 – Module Supervisory Trouble:
[01] HSM2HOSTx not responding.
[02] Keypad 01 - 16 not responding.
[04] HSM2108 01 - 15 not responding.
[05] HSM2300 01 - 04 not responding.
[06] HSM2204 01 - 04 not responding.
[08] HSM2208 01 - 16 not responding.
[09] HSM2955 is not responding.
Trouble 10 – Alternate Communicator Tamper:
[01] HSM2HOSTx Tamper.
[02] Keypad 01 - 16 Tamper.
[04] HSM2108 01 - 15 Tamper.
[05] HSM2300 01 - 04 Tamper.
[06] HSM2204 01 - 04 Tamper.
[08] HSM2208 01 - 16 Tamper.
[09] HSM2955 Tamper
Trouble 11 – Communications:
[01] TLM: Telephone line disconnected from control panel.
[02] Receiver 01-04 FTC Trouble: Failure to communicate using programmed receiver
paths.
[03] Alt. Comm SIM Lock: SIM card has incorrect or unrecognized PIN.
[04] Alt. Comm Cellular: Radio or SIM card failure, low signal strength detected, or
cellular network fault.
[05] Alt. Comm Ethernet: Ethernet connection unavailable. A valid IP address is either
not programmed or the module was unable to get an IP with DHCP.
[06] Receiver 01-04 Absent: Alternate communicator unable to initialize a receiver.
[07] Receiver 01-04 Supervision: Alternate communicator unable to communicate with
a receiver.
[09] Alt. Comm Fault: The alternate communicator has stopped responding.
[10] Alt Comm FTC Trouble: The alternate communicator has failed to communicate an
internal event not generated by the panel.
Trouble 12 – Not Networked Troubles:
[01] Zone 001- 128 Not Networked Trouble: Generated when a zone becomes out of
sync with the wireless network or has not been synchronized with the network after
enrollment.
[02] Keypad 01-16 Not Networked Trouble: Generated when a keypad becomes out of
sync with the wireless network or has not been synchronized with the network after
enrollment.
[03] Siren 01-16 Not Networked Trouble: Generated when a siren becomes out of sync
with the wireless network or has not been synchronized with the network after
enrollment.
[04] Repeater 01-08 Not Networked Trouble: Generated when a repeater becomes out of
sync with the wireless network or has not been synchronized with the network after
enrollment.
[05] User 01 - 95 Not Networked Trouble: Generated when a wireless key becomes out
of sync with the wireless network or has not been synchronized with the network after
enrollment.
IMPORTANT!
Ensure you have the following information available before contacting
Customer Support :
l Alarm controller type and version, (e.g., HSM2064 1.0):
Note: Version number can be accessed by entering [*][Installer Code]
[900] on any LCD keypad. This information is also located on a sticker on
the printed circuit board.
l List of modules connected to control panel, (e.g., HSM2108,
HSM2HOSTx etc.) .
Specifications
Zone Configuration
l 16, 32, 64, or 128 wireless zones supported and 8 hardwired
zones available on the controller
l 40 zone types and 14 programmable zone attributes
l Zone configurations available: normally closed, single EOL and
DEOL supervised
l Hardwired zone expansion (fully supervised) available using the
model HSM2108 (eight zone expander module)
l Wireless zone expansion (fully supervised) available using the
HSM2Host 2-way wireless integration module (operating at
915MHz (North America), 433MHz (Europe) and 868MHz (inter-
national)
Access Codes
l Up to 97 access codes: 94 (level 2-EN), one system master code
(level 3-EN), one installer code (level 3-EN), and one maintenance
code
l Programmable attributes for each user code (see "Access Code
Attributes" on page 1)1,000,000 access code variations (using 6-
digit codes)
l When using 6-digit access codes, the minimum number of vari-
ations of access codes are 10526 for HS2128/HS2064,13888 for
HS2032 and 20833 for HS2016
Warning Device Output
l Integral sounder capable of 85 dB @ 3m, self-powered type Z
l 2 remote, wireless indoor/outdoor warning devices supported:
models PGX901 (indoor), PGX911 (outdoor) (X=4, 8, or 9)
l Programmable as steady, pulsed or temporal three (as per
ISO8201) and temporal four (CO alarm) output
l Warning device sounds alarms in the following priority: fire, CO,
burg
Memory
l CMOS EEPROM memory
l Retains programming and system status on AC or battery failure
for 20 years min. (not verified by UL)
Power Supply
Transformer: DSC PTD1640U
Primary: 120V, 60Hz Class II
Secondary: 16.5VAC, 40VA Max.
l 1.7A regulated, supervised and integral to the control unit
l Type A as per EN50131-6 Standard
l Input ratings: 220V-240Vac, 50/60Hz, 200mA
l Transformer required, mounted in the same enclosure,
permanently connected
l Transformer secondary ratings: 16.5Vac, 40VA min.
Note: For installations using the transformer mounted inside the cabinet,
replace fuse only with the same type (20mm) rated 250V/315mA.
Regulated power supply:
l 700mA auxiliary supply, 12V DC
l Positive temperature coefficient (PTC) for Bell, Aux+ and Battery
terminals
l Reverse battery detection/protection
l Supervision for AC power and low battery
l Normal and high current battery charge options
l Supervised battery charging circuit
Current draw (panel):
l 85mA (nominal) 2A(Max)
- 9 -
