Gas Grill Parts List
436 Inch² 2-Burner
Model Grill
436 INCH² 2-BURNER
Key Part Description Part Number Qty
1. Hood Knob G1125350 2
2. Lockwasher B1008919 2
3. 1/4-20 x 1/2 Hex Head Screw T1009088 2
4. Sear Grid
®
Set (2 Pieces) 20172301 1
5. Hood with Nameplate 20174201 1
6. Briquette Replacement Box 20172206 1
7. La-Va-Grate
®
20172501 1
8. Burner Box Sub Assembly 20174302 1
9A. Burner, RH “P” Style (436 Inch² 2-Burner) Includes 26 & 27 20177203 1
9B. Burner, LH “P” Style (436 Inch² 2-Burner) Includes 26 & 27 20177204 1
11. Hair Pin Clip G1026609 2
12. Clevis Pin 20175601 2
13. Control Box 20174701 1
14. Control Knob 20173203 2
15. Igniter Knob 20182601 1
16. Manifold Support Upper with Gasket 20174901 1
17. Manifold Assembly, with Gasket (LP) 20175101 1
17. Manifold Assembly, with Gasket (Natural) 20175801 1
18. Gas Valve (LP) 20175401 2
18. Gas Valve (Natural) 20175402 2
19. Gas Orifice (LP) G1026743 2
19. Gas Orifice (Natural) G1031102 2
20. Gas regulator (LP) w/Hose 20104302 1
20. Gas regulator (Natural) G1827628 1
20. Gas regulator (System LP) G1827584 1
21. 1/8" NPT x 1-1/2 pipe nipple (Nat. & Syst. LP) G1031380 1
22. 1/8" x 3/8" npt bushing (Natural & System LP) G1026789 1
23. 1/8" npt coupling (Natural & System LP) G1031166 1
24. Rotary Igniter 20182401 1
25. Electrode and Collector Box assembly G4313758 2
A. Main Burner Electrode G1129990 2
B. #8 x 3/8 Hex Washer Head Screw (SS) 20524601 6
C. Collector box G4163670 2
D. Collector box strap G4163698 2
26. Glow Wire G4313301 2
27. 5/16-18 Self Tapping Screw G1031406 2
28. Side Shelf 20171601 1
29. Side Shelf frame 20171701 1
30. Cooking Shelf 20182901 1
31. #10 x 1/2 Hex Washer Head Screw (SS) G1026305 2
32. #10 x 5/8 Hex Washer Head Screw (SS) B1008062 6
33. Angle, Supply Line Support 20176501 1
34. 1/4-20 x 1-1/4 Screw, Black B1015956 4
35. 1/4-20 Hex Nut B1015965 4
36. Burner Locking Screw #10 x 1/2 Hex Head (SS) (Not Shown) 20525201 2
37. Shelf Assembly Screw #8 x 1-1/2 (Not Shown) 20103903 4
10 www.ducane.com
