1-800-DUCANES 3
4. With the hood open, remove the hairpin clips from the hinge clevis pins (a).
Close the hood and slide clevis pins from hood hinges (b). Lift the hood from the
burner box and place it on a nonabrasive surface.
5. Using the hex head screws and split lockwashers from the hardware bag, attach the
two hood knobs to the outside of the grill hood in the locations shown. Tighten
screws from inside rather than turning the knob, to avoid scratching paint.
6. Remove the La-Va-Grate
®
from the burner box and position the box on the
previously assembled base cabinet kit.
4. (a) 4. (b)
5.
6.
