Headlamp fairing (fig. 26.1)
Undo the middle fastening screw (1) of the wing mirrors
and remove them from the headlamp fairing supports.
Undo the two fastening screws (2, fig. 26.2) of the
headlight support and disconnect the four connectors (3)
joining the two body panels together.
Important
At reassembly, apply “medium-strength
threadlocker” onto the screw threading (1).
fig. 26.1
fig. 26.2
